Corner Sliding Glass Doors – Two-Wall Openings

Corner configurations open two walls of a room at once, meeting at a structural post or a frameless corner joint. Reinforced aluminum profiles, laminated glass and heavy-duty rollers carry the panel weight without sagging over years of use.

NFRC & AAMA testedCustom sizes & colorsFactory-direct
Product OriginCHINA
ColorCustomized Color
Lead Time15-25 days
Trade termsEXW, FOB, CIF, CFR, DDU
Shipping PortGuangzhou
Item NO.65 Munich-1

Call / WhatsApp +1 702 505 2500 · Response within 12 hours

Corner Sliding Glass Doors – Two-Wall OpeningsGet Free Quote

Product details

It has the advantages of beautiful appearance, novel style and various colors. Not only flexible to open, but also durable. It is easy to use, push and pull freely, and effectively save the space occupied by the door.

Product features

Product specifications

Suggested Maximum Size of Single Sash1500(w)*2800(h)mm
Open ModeTwo tracks: 2 glass sash, 4 glass sash Three tracks: 2 glass sash+ 1 flyscreen, 3 glass sashes, 4 glass + 2 flyscreen
Frame Thickness105mm (double tracks), 159mm (triple tracks)
Glass Thickness5mm + 20A + 5mm, insulating and tempered glass (glass technology of your choice)
Glass ConfigurationMagnetic Control Louvers Can Be Chosen, External Electric Door Can Be Made
Profile Wall ThicknessT= 1.6mm for outer frame profile, T= 3.5mm for inner frame profile, high-low bottom frame can be chosen
(A) Air Permeability (Air Tightness) m3/m.h(10 Pa) ≤1.0, Class 6
Water tightness (rainwater infiltration) Pa ≥350, Class 4
Three tracks2 glass sash+ 1 flyscreen, 3 glass sashes, 4 glass + 2 flyscreen

Send us your drawings

Our engineers respond with a system proposal within 24 hours.

Submit Drawings

Used in these projects

Frequently asked questions

What configurations are available for sliding doors?

Two-track, three-track and multi-panel configurations, with or without integrated flyscreens. Slim-frame and lift-sliding heavy-duty systems are available for large openings.

Can sliding doors be made for hurricane-prone areas?

Yes. We offer reinforced profiles and laminated or impact-rated glazing options for coastal and high-wind regions. Send us your project location and design pressure requirement for a system proposal.

What is the maximum size of a sliding door panel?

Typical single sashes go up to 1500 × 2800 mm depending on the system. Oversized panels are possible with heavy-duty hardware — our engineers confirm feasibility from your drawings.

Do sliding doors come with screens?

Yes. Retractable or track-mounted flyscreens can be integrated into the same frame system.
